AHT20+BMP280 Sensor | High Precision Temp Humidity Pressure Module | I2C Interface 3.3-5V | for Arduino ESP32 ESP8266r Station

Name: AHT20+BMP280 Sensor | High Precision Temp Humidity Pressure Module | I2C Interface 3.3-5V | for Arduino ESP32 ESP8266r Station
SKU: 69efb6e9fa02cf01c032cbdb
Price: 13 EUR
Availability: InStock

Preço atual

A partir de Preço 13 €

IVA incluído

Cor

Id Rather Be Gardening Garden Funny Childrens Kids T-Shirt Boys Girls Gift
Zhaoran 316 Stainless Steel Steamer
Six Feet Under Gift For Fans Black T-Shirt Cotton All Size Unisex T-Shirt
McbeAn Compatible for Ziglint D5 Side Brush Replacement Smart Robotic Vacuum Cleaner Spare Accessories Yellow and Black(Set3)
MODEROID Brain Powered Grancher Assembly Tipo Modelo de Plástico [Máquina Jonathan] Sem escala
adidas Adilette 22 Slides Grey Five
Cinto de Cintura Xadrez Longo e Fino Com Gravata Jeans Cachecol Acessório Decorativo Personalidade Tendência Faixa de Cabelo Acessório da Moda
Boutique De FGG Diamond Women Satin Evening Purses Bag Wedding Cocktail Metal Clutches Handbags Bridal Crystal Clutch Totes Bag
Incenso de Sândalo Premium/Varetas de Bambu com Fumaça Leve Incenso para Oferendas a Buda em Templos/Purificar o Ar Acalmar a Mente Meditação
Casaco de palhaço com estampa de bolinhas amarelas, colete sem mangas, colete de palhaço festivo, acessório de performance para festa de Halloween

Entregando em todo 🇵🇹 Portugal

10–14 dias úteis · 4 € por pedido

Os seus pagamentos e a sua privacidade estão seguros

Reembolso por não entrega

Garantia de qualidade

Logística segura

Proteção de privacidade

Segurança e conformidade

Fabricante

Caraterísticas

País de fabricação

China

Descrição

High-concerned chemical : None Material : Polymer Type : Temperature Sensor Output : Digital Sensor Origin : China Use : Temperature Sensor

p{margin-block-start: 0; margin-block-end: 0}All-in-One Environmental Sensing: Precision Data for Temperature, Humidity, and Pressure. Key Features & Benefits 3-in-1 Precision: Combines AHT20 and BMP280 for simultaneous, high-accuracy reading of temperature, humidity, and barometric pressure.

Digital & Stable: I2C digital output ensures stable data transmission, resistant to interference.

Easy to Power: Wide operating voltage (3.3V to 5V DC), compatible with Arduino and ESP32 without complex power regulation.

Plug & Play: Standard GROVE 4-pin connector allows for quick connection without soldering.

Low Power Consumption: Optimized for battery-powered applications and long-term monitoring.

Product Description Need reliable environmental data for your project? This compact module packs two premium sensors (AHT20 & BMP280) into one board, delivering three key metrics at once. Simplify your weather station, smart home climate control, or IoT device with easy I2C integration.

Important Notes / How to Use

I2C Address Conflict: This module contains two I2C devices. The AHT20 address is 0x38, and the BMP280 address is 0x76 or 0x77. Ensure your code uses the correct addresses for each sensor.

Voltage Level Compatibility: The I2C logic level must match your microcontroller. If using a 5V MCU (like Arduino Uno), verify I2C line 5V-tolerance or use a level shifter.

Software Library Required: You MUST install the dedicated Arduino libraries for AHT20 and BMP280 (e.g., Adafruit_AHTX and Adafruit_BMP280) for proper operation.

Environmental Factors: For accurate readings, avoid placing the module near heat sources or in direct sunlight.

Specifications

Core Sensors: AHT20 + BMP280

Interface: I2C (GROVE-4PIN)

Supply Voltage: 3.3V - 5V DC

AHT20 (Temp & Humidity): Temperature Range: -40°C ~ +85°C (Accuracy: ±0.3°C) | Humidity Range: 0%RH ~ 100%RH (Accuracy: ±2%RH)

BMP280 (Pressure & Temp): Pressure Range: 300hPa ~ 1100hPa (Accuracy: ±1 hPa)

Package Includes 1 x AHT20+BMP280 Temperature Humidity Pressure Sensor Module.
