Marine Outboard Motor Inch Tilt Side White

Description:

- Front cover is made of 316 stainless steel.

- Shell is made of PBT+GF20%, melting point 220℃, high temperature resistance, chemical resistance and oil resistance.

- The highly transparent curved surface PC forms a double-layer anti-fog structure with the curved glass.

- Dial is made of PC material, which is resistant to high temperatures and high modulus of elasticity.

- Waterproof and dustproof grade IP67.2. Can match a variety of sensor signals, in addition to 0~190Ω/240~33Ω, 0~5V/0.5~4.5V, 4~20mA, can also connect any analog signal.

- The meter comes with an alarm signal and does not require an additional alarm signal from the sensor.

- Using a high-precision stepper motor, the pointer acceleration and deceleration curve motion can extend the life of the motor.

- High-brightness LEDs are used for backlighting, which has high brightness and long life.

Specification:

- Right Side Display, White Dial

- Material: PC

- Size: 8x8x7cm / 3.1x3.1x2.75 inch

- Working Temperature: -40~85℃

- Protection Level: IP67

- Working Voltage: DC 8~16V, DC 18~32V

- Working Current:<100mA

- Display Accuracy:<3°

- 90° display angle

- 52mm (2") mounting hole

Package Includes: 1 Piece Gauge (back screw , gasket) 1 Piece Cable 1 Piece Rubber Stopper 1 Piece Instruction Manual
