Feature:
1. The original intention of SDI to HDMI converter is to display SD?SDI, HD?SDI, and 3G?SDI signals on HDMI monitors. At the same time, it ensures 2.970 Gbit/s high?speed lossless signal transmission. It is also possible to separate and convert the audio signal in the SDI signal and embed it into the HDMI signal to achieve simultaneous long?distance sound and image transmission.
2. Industrial?grade power supply technology, support 5V?12V wide voltage, first?class output effect, fully meet the professional requirements of broadcasting studios and non?linear editing systems, strong stability, 24 hours of uninterrupted work.
3. Audio and image synchronous output, video synchronization without delay, the use of precision?level chips for stable and efficient transmission, effectively solving various unstable factors, such as: snowflakes, stuttering, delay, etc., HDIM resolution supports up to 1080P, so that your monitor can still play HD SDI signal.
4. Installation of the SDI to HDMI converter is simple and convenient, and multiple converters can be connected together to extend the signal over a long distance and the converter supports up to 8 channels of 48 KHz audio.
5. Support HDMI1.3 version, backward compatible with HDMI 1.2/1.1, compatible with multiple SDI signals: SD?SDI/HD?SDI/3G?SDI. Using Scaler zoom technology, it can convert non?standard SDI signals into standard HDMI 720P/1080P signal output to adapt to different displays. And automatically recognize the resolution, support full HD 1080P@60Hz. The output supports SMPTE 425M, SMPTE 424M, SMPTE 292M, SMPTE 259M?C, etc.
Specification:
Condition: 100percent Brand New
Item Type: HDMI To SDI Converter
Material: Ferroalloy
Color: As Pictures Shown
Size: Approx. 80mm x 41mm x 25 mm / 3.1 x 1.6 x 1in
Input Interface: BNC (SD-SDI/HD-SDI/3G-SDI)
Output Interface: HDMI
Input/Output Resolution: 480i, 576i, 720p@50/59.94,60. 1080i@50/59.94/60. 1080p@23.97/24/25/29.97/30/50/59.94/60
SDI Transmission Rate: 2.970 Gbit/s and 2.970/1.001 Gbit/s
Adaptable Power Supply Specification: DC 5V-12V
ESD Human Body Protection Model: +/-8kV (Air Discharge), +/-4kV (Contact Discharge)
Weight: Approx. 150g / 5.3oz
Working Temperature: 0 degrees C-40 degrees C / 32 degrees F-104 degrees F
Storage Temperature: -20 degrees C-60 degrees C / -4 degrees F-140 degrees F
Relative Humidity: 20-90percent RH (No Condensation)
Maximum Power Consumption: 5W.
Package List:
1 x SDI Converter Host1 x Power Adapter(Input AC100-240V 50/60hz 0.25A Output 5V/1A)1 x Manual
