Remote Control Duplicator 4 Button Garage Door Gate Opener 315MHz/433MHz Universal Cloning Remote Replacement for Electric Gate
Feature:
1. Compatibility: Works with fixed code and learning code wireless remote controls such as PT2242, PT2260, PT2262, PT2264, EV1527, EV1528, 527, PT2240, SMC918, HT-12E, AX5326-3, AX5326-4, AX026, HT600, HT680, HT6207, HT6010, HT6012, HT6014, MC145026, HT640, SMC926, HT6P12E, HT6P20D, HT12D, and more. Also compatible with VD5326 that supports HCS301 codes from various manufacturers.
2. Wide Compatibility With Popular Brands: Compatible with well-known brands such as for CAME, K323A, K327A, for Baisheng's 433MHz T18T19, for Baisheng's 315MHz welding code, for Sheya's 433MHz flashlights, and older versions of Sheya's 433MHz with 1527 learning code.
3. Suitable For Copying Various Remote Controls: Enables copying of remote controls for electric gates, access control systems, roller shutters, retractable doors, boom barriers, garage doors, home security systems, motorcycle anti-theft systems, electric vehicle anti-theft systems, car alarm systems, security alarm systems, wireless lighting controls, and more. Enhance convenience by duplicating remote control keys.
4. Easy Operation: Step 1: Clearing codes - Simultaneously press and hold the two front (top) buttons until the LED indicator blinks three times. Release one of the buttons while keeping the other button pressed. Tap the released button three times, and the LED will start flashing rapidly to indicate successful code clearing (a cleared remote control won't light up when short-pressed). Note: For Oumake and Longkeduo, you need to pair all four buttons first and then simultaneously press both AC buttons on the remote control for 5 seconds to decode before normal switching can occur. Step 2: Copying - Hold the original remote control in one hand and the copy remote control in another hand. Bring them close together and press the desired button to be copied on both remotes. After the LED indicator flashes rapidly three times, it will remain lit, indicating successful copying. The same method applies to other button operations.
5. Restoration: If accidentally cleared useful codes without copying other remotes, you can simultaneously press the two back (bottom) buttons on the remote control. After the LED indicator flashes rapidly three times, it indicates successful restoration.
Specification:
Origin: Mainland China
Use: Electric Door
Wireless Communication: RF
Product name: Black sliding cover four-button single-frequency copy remote control
Product model: AK-5566TX
Product frequency: 315/433MHZ (optional)
Remote control distance: 50-100m or more (different according to the supporting transmitter)
Working voltage: DC12V
Number of keys: 4 keys
Oscillation resistance: according to customer requirements
Application areas: copy and pairing of various door and window controllers and other industrial controls and other remote controls
Modulation method: ASK amplitude modulation
Product weight: 23g
Product size: 62*39*15mm 2.44x1.54x0.59inch
Product details: This series of new wireless remote controls are used in conjunction with the micro copy machine launched by our company. They can produce 1527 (learning code) 2260 (fixed code) remote controls at will, and can change the data bits and oscillation resistance of the remote control to get what you want. The essential remote control. Easy to use and flexible to operate, it can solve common problems such as inventory preparation and delivery delays for dealers and supporting manufacturers.
Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
