Feature:
1. Wider Applications: Permanent magnet DC motor can be used for candy floss machine, small cutting table, grinder and other mechanical equipment.
2. High Speed Operation: The DC motor can run at a high speed, drive smoothly without noise, and has a large torsion.
3. Copper Stator Winding: The stator winding of the motor uses copper wire, which has good conductivity and keeps the motor running stably.
4. Support CW and CCW: Support CW and CCW control, can switch the rotation direction without removing wires, with strong practicability.
5. For DIY Generators: With a rated power of 30W, this permanent magnet DC motor is an ideal choice for DIY generators.
Specification:
Item Type: DC Motor
Model: XD 3420 thread
Number of Poles: 2 poles
Rated Power: 30W
Application: Candy floss machine, medical equipment
Voltage (VDC)No Load Revolution (RPM MIN)No Load Current (A)Rated Revolution (RPM MIN)Rated Current (A)Locked Rotor Current (A)12V35000.3124002.423.124V70000.3551002.763.37.
Package List:
1 x DC Motor
Note:
3000 hours of life, carbon brush can be replaced.
